TRT Only L2 Alignment

This L2 TRT alignment is in principle independent of the Si alignment
When aligning the barrel modules With 5Dof the alignment cannot converge.
     Rotations around global X and Y seem unconstrained.
With 3Dof the alignment converges
     2 translations and rotations around globalZ.
     There will be 3 trivially unconstrained DoFs.

Reproduced the L1 alignment with rel15 with the Si constants from the 1st reprocessign.
    See above (TRT Tracking improvements from Realease 14->15) for details about the L1 alignment.
After this L1 alignment reproduced the L2 alignment with rel15.
    Aligned with Both sides A and C
     Have sucsessfully found the trivial unconstrained DoFs. See presentation below.
        -Improvement in TRT Only tracks monitoring plots
        -Remaining inconsistency in combined tracks
      Detail here.

The translations found in this alignment can be seen in the following plot.
Note that this L2 alignment can explain why the D0 cut removes the phi structure.


Despite the L2 alignment with TRT only tracks there are still A and C differences
See A/C differences from the main page.
